Synology DiskStation DS718+
translation missing: en.products.product.regular_price ₱37,095.00
translation missing: en.products.product.regular_price ₱37,095.00

DiskStation DS718+

High performance NAS optimized for intensive workloads



Flexible scalability meeting growing needs

Powered by a quad-core processor and AES-NI hardware encryption engine, DS718+ delivers excellent file transfer speeds. With the scalability to expand up to 7 drives with Synology Expansion Unit DX517 and the support for real-time 4K/1080p video transcoding, DS718+ is ideal for centralizing data backup and storing ultra-high definition media contents.

CPU

Quad-core burst up to 2.3GHz

RAM options

DDR3L 2GB, up to 6GB

Encryption Performance

Up to 226 MB/s reading and 184 MB/s writing

Transcoding

2-channel 4K H.264/H.265 video transcoding

Btrfs: Next generation storage efficiency

Btrfs file system introduces the most advanced storage technologies to meet the management needs of modern large scale businesses:

Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders

Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots

File or folder level data restoration makes data recovery fast and flexible

Automatic file self-healing detects and recovers corrupted files without user intervention

Ultimate file management and sharing

File Station is a web-based, fast and secure management tool built to allow easy, drag-and-drop operations without requiring any complex setup on Mac or PC. Advanced search and filtering tools allow for easy organization and file sharing. For complete compatibility, DS718+ supports the following protocols: AFP, FTP, iSCSI, NFS, SMB, and WebDAV.

Synchronize files across your devices

Cloud Station Suite provides real-time data synchronization across all your devices and other Synology NAS. "Intelliversioning" keeps the most important file versions to better utilize storage space. Learn more

Cloud Station Sharesync

Cloud Station Drive

Cloud Station Server

DS Cloud

Real-time collaboration on your private cloud

Office is a collaboration package combining the convenience and usability of public clouds with the data privacy and security guaranteed by private clouds. It allows you to work seamlessly together on documents and spreadsheets in a protected environment.

Real-time collaboration on the same online documents to boost productivity,

Instant communication on Synology Chat during the editing of documents or spreadsheets

Version control for you to navigate all the changes and retrieve previous versions with just a click

4K Multimedia Server

Access and stream your 4K media content anytime and anywhere. DS718+ supports 4K H.264/H.265 online transcoding via Video Station and DS video, allowing 4K videos to be converted and played on the fly on other computers, smartphones, and media players that originally do not support Ultra HD formats. Learn more

Powered by Synology DSM

Surveillance Station

Complete surveillance solution for recording, monitoring, and management.

Learn more

Desktop Backup

Simplified backup solution for your Mac, PC, and mobile devices.

Learn more

Hyper Backup

Store multiple backup versions with block-level incremental data backup and cross-version deduplication.

Learn more

DSM UI

Award-winning operating system with an intuitive user interface and powerful capabilities.

Learn more

Security

Comprehensive built-in security tools are constantly updated to tackle evolving threats and protect your devices.

Learn more

All-in-one server

Save additional investment by integrating various network services, web/mail services, management applications into your NAS.

Learn more
Hardware Specifications
CPU
CPU Model Intel Celeron J3455
CPU Architecture 64-bit
CPU Frequency Quad Core 1.5 burst up to 2.3 GHz
Hardware Encryption Engine (AES-NI)
Hardware Transcoding Engine H.264 (AVC), H.265 (HEVC), MPEG-2 and VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 30
Memory
System Memory 2 GB DDR3L
Memory Module Pre-installed 2GB (1 x 2GB)
Total Memory Slots 2
Memory Expandable up to 6 GB (2 GB + 4 GB)
Storage
Drive Bays 2
Maximum Drive Bays with Expansion Unit 7
Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA HDD
  • 2.5" SATA SSD
Maximum Internal Raw Capacity 28 TB (14 TB drive x 2) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units 98 TB (28 TB + 14 TB drive x 5) (Capacity may vary by RAID types)
Maximum Single Volume Size 108 TB
Hot Swappable Drive
Notes
  • "Compatible drive type" indicates the drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
  • Expansion of the internal volume is only supported if the combined single volume size does not exceed the maximum limit of 108TB.
External Ports
RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
USB 3.0 Port 3
eSATA Port 1
Copy Button
File System
Internal Drives
  • Btrfs
  • EXT4
External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 157 mm x 103.5 mm x 232 mm
Weight 1.74 kg
Others
System Fan 92 mm x 92 mm x 1 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Brightness adjustable front LED indicators
Power Recovery
Noise Level* 18.4 dB(A)
Scheduled Power On/Off
Wake on LAN/WAN
Power Supply Unit / Adapter 65W
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 20.1 W (Access)
9.1 W (HDD Hibernation)
British Thermal Unit 68.58 BTU/hr (Access)
31.05 BTU/hr (HDD Hibernation)
Environment Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
  • EAC
  • VCCI
  • CCC
  • RCM
  • KC
  • FCC
  • CE
  • BSMI
Warranty 3 Years
Notes
  • Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
  • Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
DSM Specifications ( See more )
Storage Management
Maximum Internal Volume Number 512
Maximum iSCSI Target Number 128
Maximum iSCSI LUN 256
iSCSI LUN Clone/Snapshot, Windows ODX
SSD Read/Write Cache (White Paper)
SSD TRIM
Supported RAID Type
  • Synology Hybrid RAID
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5 (with Expansion Unit)
  • RAID 6 (with Expansion Unit)
  • RAID 10 (with Expansion Unit)
RAID Migration
  • Basic to RAID 1
  • Basic to RAID 5 (with Expansion Unit)
  • RAID 1 to RAID 5 (with Expansion Unit)
  • RAID 5 to RAID 6 (with Expansion Unit)
Volume Expansion with Larger HDDs
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5 (with Expansion Unit)
  • RAID 6 (with Expansion Unit)
Volume Expansion by Adding a HDD
  • Synology Hybrid RAID
  • RAID 5 (with Expansion Unit)
  • RAID 6 (with Expansion Unit)
  • JBOD (with Expansion Unit)
Global Hot Spare Supported RAID Type
  • Synology Hybrid RAID
  • RAID 1 (with Expansion Unit)
  • RAID 5 (with Expansion Unit)
  • RAID 6 (with Expansion Unit)
  • RAID 10 (with Expansion Unit)
File Sharing Capacity
Maximum Local User Accounts 2048
Maximum Local Groups 256
Maximum Shared Folder 512
Maximum Shared Folder Sync Tasks 8
Maximum Concurrent CIFS/AFP/FTP Connections 500
Maximum Concurrent CIFS/AFP/FTP Connections (with RAM expansion) 1500
Windows Access Control List (ACL) Integration
NFS Kerberos Authentication
High Availability Manager
Log Center
Syslog Events per Second 800
Virtualization
VMware vSphere 6 with VAAI
Windows Server 2012
Windows Server 2012 R2
Citrix Ready
OpenStack
Add-on Packages (learn more about the complete add-on package list)
Antivirus by McAfee (Trial)
Central Management System
Chat
Maximum Users 1500
Notes
  • The number of concurrent HTTP connections for Chat was configured to the maximum.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
Cloud Station Server
Maximum Number of Concurrently Connected Devices 500
Maximum Number of Concurrently Connected Devices (with RAM expansion) 1500
Maximum Number of Hosted Files (btrfs) 1,000,000
Maximum Number of Hosted Files (ext4) 1,000,000
Notes
  • The maximum number of concurrently connected devices refers to the maximum number of devices that can remain connected at the same time.
  • The maximum number of hosted files refers to the maximum number of files that can be indexed and hosted by the Cloud Station Server service. RAM expansion was not used during testing.
  • Non-encrypted shared folders were used during the aforementioned testing.
Document Viewer
Download Station
Maximum Concurrent Download Tasks 80
Drive
Maximum Number of Hosted Files 500,000
Maximum Number of Concurrent Connections for PC Clients 450
Notes
  • The Btrfs file system was used for the purpose of testing.
  • The maximum number of hosted files refers to the maximum number of files that can be indexed and hosted by the Drive service.
  • The maximum number of concurrent connections refers to the maximum number of connections that can be maintained when the maximum number of hosted files was reached.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Non-encrypted shared folders were used during the aforementioned testing.
exFAT Access (optional)
MailPlus / MailPlus Server
Free Email Accounts 5 (Licenses required for additional accounts)
Maximum number of concurrent users Up to 100
Maximum Server Performance 1,052,000 emails per day, approx. 32GB
Notes
  • The CPU and RAM usage were both under 80% when testing the maximum number of concurrent users.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Read-write SSD cache was enabled in 5-bay (and above) NAS models with 2 SSDs units installed.
  • The performance of the mail system will slightly decrease in high-availability mode due to data synchronization between the two servers.
  • Functions that were enabled in all of the tests above: anti-spam, anti-virus, DNSBL, greylist, content scan, full-text search (English only).
Media Server
DLNA Compliance
Moments
Facial recognition
Subject recognition
Office
Maximum Users 1800
Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Snapshot Replication
Maximum Snapshots per Shared Folder 1024
Maximum of system snapshots 65536
Surveillance Station
Maximum IP cam (Licenses required) 40 (including 2 Free License) (See All Supported IP Cameras)
Total FPS (H.264)* 1200 FPS @ 720p (1280x720)
800 FPS @ 1080p (1920×1080)
350 FPS @ 3M (2048x1536)
280 FPS @ 5M (2591x1944)
170 FPS @ 4K (3840x2160)
Total FPS (H.265)* 1200 FPS @ 720p (1280x720)
1200 FPS @ 1080p (1920×1080)
600 FPS @ 3M (2048x1536)
480 FPS @ 5M (2591x1944)
200 FPS @ 4K (3840x2160)
Total FPS (MJPEG)* 450 FPS @ 720p (1280x720)
250 FPS @ 1080p (1920×1080)
200 FPS @ 3M (2048x1536)
100 FPS @ 5M (2591x1944)
Notes Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
Video Station
Video Transcoding 4K Group 1 (See more)
Maximum Transcoding Channel Number 2 channel, 30 FPS @ 4K (4096 x 2160), H.264 (AVC)/H.265 (HEVC) or
2 channel, 30 FPS @ 1080p (1920×1080), H.264 (AVC)/H.265 (HEVC)/MPEG-2/VC-1
Virtual Machine Manager
Recommended Virtual Machine Instances 2 (Learn more)
Recommended Virtual DSM Number (Licenses required) 2 (including 1 Free License)
Notes
  • Virtual Machine Manager is not supported on hosts running Synology High Availability.
  • The specifications vary depending on system configuration and memory size.
VPN Server
Maximum Connections 20
Environment & Packaging
Environment RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
  • Quick Installation Guide X 1
Optional Accessories
  • Surveillance Device License Pack
  • D3NS1866L-4G DDR3 non-ECC SO-DIMM
  • Expansion Unit: DX517 X 1
  • VS360HD
  • VS960HD
Synology DiskStation DS218
translation missing: en.products.product.regular_price ₱22,890.00
translation missing: en.products.product.regular_price ₱22,890.00

DiskStation DS218

Versatile 2-bay NAS for small offices and home users



Versatile NAS server for centralized file storage and real-time 4K H.265 video transcoding

Synology DS218 comes with a new 64-bit quad-core processor, delivering excellent data transfer speed, large storage volume management, and 10-bit 4K H.265 video transcoding on the fly.

CPU

Quad-core 1.4GHz

Memory

2GB DDR4

Performance

Over 112 MB/s and 112 MB/s sequential read and write

Capacity

Surpass 16TB per single volume

Ultimate file management and sharing

File Station is a web-based, fast and secure management tool built to allow easy, drag-and-drop operations without requiring any complex setup on Mac or PC. Advanced search and filtering tools allow for easy organization and file sharing. For complete compatibility, DS218 supports the following protocols: AFP, FTP, iSCSI, NFS, SMB, and WebDAV.

Synchronize files across your devices

Cloud Station Suite provides real-time data synchronization across all your devices and other Synology NAS. "Intelliversioning" keeps the most important file versions to better utilize storage space. Learn more

Cloud Station Sharesync

Cloud Station Drive

Cloud Station Server

DS Cloud

Easy backup solutions

Back up any computer or mobile device with Synology's comprehensive multi-versioning backup solution. You can protect your computer and NAS against malicious attacks including the rising encryption-based ransomware threats.

Easy file access with QuickConnect

Access files on your Synology NAS over the Internet without the hassle of setting up port forwarding rules, DDNS, or other complicated network settings. QuickConnect allows you to connect via a secure, customizable address, so that you can instantly access media and work files on any Internet-connected device with no additional charge.

4K Multimedia Server

Access and stream your favorite 4K content anywhere, anytime. DS218 supports 10-bit 4K H.265 online transcoding. With Video Station and DS video, you can convert and play 4K videos from any computer, mobile device, or other media players that don't support Ultra HD formats.

Powered by Synology DSM

Surveillance Station

Complete surveillance solution for recording, monitoring, and management.

Learn more

Desktop Backup

Simplified backup solution for your Mac, PC, and mobile devices.

Learn more

Public Cloud Integration

Backup and synchronize data easily between your public cloud accounts and your NAS.

Learn more

DSM UI

Award-winning operating system with an intuitive user interface and powerful capabilities.

Learn more

Security

Comprehensive built-in security tools are constantly updated to tackle evolving threats and protect your devices.

Learn more

Multimedia

Complete multimedia solution for management, streaming, and playback.

Learn more
  • 1Status indicator
  • 2LAN indicator
  • 3Drive status indicator
  • 4USB 2.0 port
  • 5USB copy button
  • 6Power button and indicator
  • 7USB 3.0 port
  • 8Reset button
  • 91GbE RJ-45 port
  • 10Power port
  • 11Fan
  • 12Kensington Security Slot





Hardware Specifications
CPU
CPU Model Realtek RTD1296
CPU Architecture 64-bit
CPU Frequency Quad Core 1.4 GHz
Hardware Encryption Engine
Hardware Transcoding Engine 10-bit H.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60
Memory
System Memory 2 GB DDR4
Storage
Drive Bays 2
Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA HDD
  • 2.5" SATA SSD
Maximum Internal Raw Capacity 28 TB (14 TB drive x 2) (Capacity may vary by RAID types)
Maximum Single Volume Size 108 TB
Hot Swappable Drive
Notes
  • "Compatible drive type" indicates the drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
External Ports
RJ-45 1GbE LAN Port 1
USB 2.0 Port 1
USB 3.0 Port 2
Copy Button
File System
Internal Drives
  • Btrfs
  • EXT4
External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 165 mm x 108 mm x 233.2 mm
Weight 1.3 kg
Others
System Fan 92 mm x 92 mm x 1 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Brightness adjustable front LED indicators
Power Recovery
Noise Level* 19.3 dB(A)
Scheduled Power On/Off
Wake on LAN/WAN
Power Supply Unit / Adapter 60W
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 14.99 W (Access)
5.78 W (HDD Hibernation)
British Thermal Unit 51.15 BTU/hr (Access)
19.72 BTU/hr (HDD Hibernation)
Environment Temperature
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
  • EAC
  • CCC
  • RCM
  • KC
  • FCC
  • CE
  • BSMI
Warranty 2 Years
Notes
  • Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
  • Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
DSM Specifications ( See more )
Storage Management
Maximum Internal Volume Number 256
Maximum iSCSI Target Number 10
Maximum iSCSI LUN 10
SSD TRIM
Supported RAID Type
  • Synology Hybrid RAID
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
RAID Migration Basic to RAID 1
Volume Expansion with Larger HDDs
  • Synology Hybrid RAID
  • RAID 1
Volume Expansion by Adding a HDD Synology Hybrid RAID
File Sharing Capacity
Maximum Local User Accounts 2048
Maximum Local Groups 256
Maximum Shared Folder 256
Maximum Shared Folder Sync Tasks 2
Maximum Concurrent CIFS/AFP/FTP Connections 200
Windows Access Control List (ACL) Integration
NFS Kerberos Authentication
Log Center
Syslog Events per Second 400
Add-on Packages (learn more about the complete add-on package list)
Chat
Maximum Users 500
Notes
  • The number of concurrent HTTP connections for Chat was configured to the maximum.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
Cloud Station Server
Maximum Number of Concurrently Connected Devices 200
Maximum Number of Hosted Files (ext4) 100,000
Notes
  • The maximum number of concurrently connected devices refers to the maximum number of devices that can remain connected at the same time.
  • The maximum number of hosted files refers to the maximum number of files that can be indexed and hosted by the Cloud Station Server service. RAM expansion was not used during testing.
  • Non-encrypted shared folders were used during the aforementioned testing.
Download Station
Maximum Concurrent Download Tasks 80
Drive
Maximum Number of Hosted Files 100,000
Maximum Number of Concurrent Connections for PC Clients 200
Notes
  • The EXT4 file system was used for the purpose of testing.
  • The maximum number of hosted files refers to the maximum number of files that can be indexed and hosted by the Drive service.
  • The maximum number of concurrent connections refers to the maximum number of connections that can be maintained when the maximum number of hosted files was reached.
  • Non-encrypted shared folders were used during the aforementioned testing.
exFAT Access (optional)
Media Server
DLNA Compliance
Moments
Facial recognition
Subject recognition
Office
Maximum Users 200
Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Snapshot Replication
Maximum Snapshots per Shared Folder 256
Maximum of system snapshots 4096
Surveillance Station
Maximum IP cam (Licenses required) 20 (including 2 Free License) (See All Supported IP Cameras)
Total FPS (H.264)* 600 FPS @ 720p (1280x720)
300 FPS @ 1080p (1920×1080)
200 FPS @ 3M (2048x1536)
150 FPS @ 5M (2591x1944)
110 FPS @ 4K (3840x2160)
Total FPS (H.265)* 600 FPS @ 720p (1280x720)
300 FPS @ 1080p (1920×1080)
240 FPS @ 3M (2048x1536)
200 FPS @ 5M (2591x1944)
180 FPS @ 4K (3840x2160)
Total FPS (MJPEG)* 240 FPS @ 720p (1280x720)
200 FPS @ 1080p (1920×1080)
130 FPS @ 3M (2048x1536)
80 FPS @ 5M (2591x1944)
Notes Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
Video Station
Video Transcoding 4K Group 3 (See more)
Maximum Transcoding Channel Number 1 channel, 60 FPS @ 4K (4096 x 2160), H.265 (HEVC), 10-bit or
1 channel, 30 FPS @ 1080p (1920 × 1080), H.264 (AVC)/MPEG-4 Part 2 (XVID, DIVX5)/MPEG-2/VC-1
Notes
VPN Server
Maximum Connections 20
Environment & Packaging
Environment RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 1
  • Quick Installation Guide X 1
Optional Accessories
  • Surveillance Device License Pack
  • VS360HD
  • VS960HD



Synology DiskStation DS118
translation missing: en.products.product.regular_price ₱15,480.00
translation missing: en.products.product.regular_price ₱15,480.00

High-performance 1-bay NAS for small office and home users



Versatile, powerful and compact storage server

Synology DS118 comes with a new 64-bit quad-core processor, delivering excellent data transfer speed and 10-bit 4K H.265 video transcoding on the fly.

CPU

Quad-core 1.4 GHz

Memory

1GB DDR4

Performance

Over 113 MB/s and 112 MB/s sequential reading and writing

Eco-friendly

9.4 W / 4.22 W Access / Hibernation power consumption

Ultimate file management and sharing

File Station is a web-based, fast and secure management tool built to allow easy, drag-and-drop operations without requiring any complex setup on Mac or PC. Advanced search and filtering tools allow for easy organization and file sharing. For complete compatibility, DS118 supports the following protocols: AFP, FTP, iSCSI, NFS, SMB, and WebDAV.

Synchronize files across your devices

Cloud Station Suite provides real-time data synchronization across all your devices and other Synology NAS. "Intelliversioning" keeps the most important file versions to better utilize storage space. Learn more

Cloud Station Sharesync

Cloud Station Drive

Cloud Station Server

DS Cloud

Easy file access with QuickConnect

Access files on your Synology NAS over the Internet without the hassle of setting up port forwarding rules, DDNS, or other complicated network settings. QuickConnect allows you to connect via a secure, customizable address, so that you can instantly access media and work files on any Internet-connected device with no additional charge.

4K Multimedia Server

Access and stream your favorite 4K content anywhere, anytime. DS118 supports 10-bit 4K H.265 online transcoding. With Video Station and DS video, you can convert and play 4K videos from any computer, mobile device, or other media players that don't support Ultra HD formats.

Powered by Synology DSM

Surveillance Station

Complete surveillance solution for recording, monitoring, and management.

Learn more

Desktop Backup

Simplified backup solution for your Mac, PC, and mobile devices.

Learn more

Public Cloud Integration

Backup and synchronize data easily between your public cloud accounts and your NAS.

Learn more

DSM UI

Award-winning operating system with an intuitive user interface and powerful capabilities.

Learn more

Security

Comprehensive built-in security tools are constantly updated to tackle evolving threats and protect your devices.

Learn more

Multimedia

Complete multimedia solution for management, streaming, and playback.

Learn more
  • 1Status indicator
  • 2LAN indicator
  • 3Drive status indicator
  • 4Power button and indicator
  • 5Fan
  • 6Reset button
  • 7Kensington Security Slot
  • 8USB 3.0 port
  • 91GbE RJ-45 port
  • 10Power port



Hardware Specifications
CPU
CPU Model Realtek RTD1296
CPU Architecture 64-bit
CPU Frequency Quad Core 1.4 GHz
Hardware Encryption Engine
Hardware Transcoding Engine 10-bit H.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60
Memory
System Memory 1 GB DDR4
Storage
Drive Bays 1
Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA HDD (with optional 2.5" Disk Holder)
  • 2.5" SATA SSD (with optional 2.5" Disk Holder)
Maximum Internal Raw Capacity 14 TB (14 TB drive x 1) (Capacity may vary by RAID types)
Maximum Single Volume Size 108 TB
Hot Swappable Drive
Notes
  • "Compatible drive type" indicates the drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
External Ports
RJ-45 1GbE LAN Port 1
USB 3.0 Port 2
File System
Internal Drives EXT4
External Drives
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*
Notes exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth) 166 mm x 71 mm x 224 mm
Weight 0.7 kg
Others
System Fan 60 mm x 60 mm x 1 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
  • Low-power Mode
Brightness adjustable front LED indicators
Power Recovery
Noise Level* 16.7 dB(A)
Scheduled Power On/Off
Wake on LAN/WAN
Power Supply Unit / Adapter 36W
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 9.4 W (Access)
4.22 W (HDD Hibernation)
British Thermal Unit 32.1 BTU/hr (Access)
14.41 BTU/hr (HDD Hibernation)
Environment Temperature
Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
  • EAC
  • CCC
  • RCM
  • KC
  • FCC
  • CE
  • BSMI
Warranty 2 Years
Notes
  • Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
  • Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
DSM Specifications ( See more )
Storage Management
Maximum Internal Volume Number 1
Maximum iSCSI Target Number 10
Maximum iSCSI LUN 10
SSD TRIM
Supported RAID Type Basic
File Sharing Capacity
Maximum Local User Accounts 2048
Maximum Local Groups 256
Maximum Shared Folder 256
Maximum Shared Folder Sync Tasks 2
Maximum Concurrent CIFS/AFP/FTP Connections 200
Windows Access Control List (ACL) Integration
NFS Kerberos Authentication
Log Center
Syslog Events per Second 100
Add-on Packages (learn more about the complete add-on package list)
Chat
Maximum Users 500
Notes
  • The number of concurrent HTTP connections for Chat was configured to the maximum.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
Cloud Station Server
Maximum Number of Concurrently Connected Devices 200
Maximum Number of Hosted Files (ext4) 100,000
Notes
  • The maximum number of concurrently connected devices refers to the maximum number of devices that can remain connected at the same time.
  • The maximum number of hosted files refers to the maximum number of files that can be indexed and hosted by the Cloud Station Server service. RAM expansion was not used during testing.
  • Non-encrypted shared folders were used during the aforementioned testing.
Download Station
Maximum Concurrent Download Tasks 30
Drive
Maximum Number of Hosted Files 100,000
Maximum Number of Concurrent Connections for PC Clients 200
Notes
  • The EXT4 file system was used for the purpose of testing.
  • The maximum number of hosted files refers to the maximum number of files that can be indexed and hosted by the Drive service.
  • The maximum number of concurrent connections refers to the maximum number of connections that can be maintained when the maximum number of hosted files was reached.
  • Non-encrypted shared folders were used during the aforementioned testing.
exFAT Access (optional)
Media Server
DLNA Compliance
Moments
Facial recognition
Subject recognition
Office
Maximum Users 200
Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Surveillance Station
Maximum IP cam (Licenses required) 15 (including 2 Free License) (See All Supported IP Cameras)
Total FPS (H.264)* 450 FPS @ 720p (1280x720)
180 FPS @ 1080p (1920×1080)
110 FPS @ 3M (2048x1536)
80 FPS @ 5M (2591x1944)
40 FPS @ 4K (3840x2160)
Total FPS (H.265)* 450 FPS @ 720p (1280x720)
450 FPS @ 1080p (1920×1080)
210 FPS @ 3M (2048x1536)
120 FPS @ 5M (2591x1944)
60 FPS @ 4K (3840x2160)
Total FPS (MJPEG)* 210 FPS @ 720p (1280x720)
70 FPS @ 1080p (1920×1080)
50 FPS @ 3M (2048x1536)
30 FPS @ 5M (2591x1944)
Notes Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
Video Station
Video Transcoding 4K Group 3 (See more)
Maximum Transcoding Channel Number 1 channel, 60 FPS @ 4K (4096 x 2160), H.265 (HEVC), 10-bit or
1 channel, 30 FPS @ 1080p (1920 × 1080), H.264 (AVC)/MPEG-4 Part 2 (XVID, DIVX5)/MPEG-2/VC-1
Notes
VPN Server
Maximum Connections 20
Environment & Packaging
Environment RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • RJ-45 LAN Cable X 1
  • Quick Installation Guide X 1
Optional Accessories
  • Surveillance Device License Pack
  • Disk Holder: Type C
  • VS360HD
  • VS960HD



Synology Embedded DataStation EDS14
translation missing: en.products.product.regular_price ₱24,960.00
translation missing: en.products.product.regular_price ₱24,960.00

Embedded DataStation  EDS14

Palm-sized NAS server for rigorous environments



Feature-rich, environment-resistant NAS in a compact body

EDS14 is a feature-rich mini NAS server combining portability with endurance, suitable for extreme environment deployment. EDS14 delivers remarkable read/write performance - up to 103.54 MB/s reading and 61.13 MB/s writing speeds with a USB 3.0 drive in a Windows® environment.

CPU

1.2GHz

Memory

512MB DDR3

External ports

Dual 1GbE LAN, USB 3.0/2.0 port, SDXC/UHS-I SD card reader

Eco-friendly

8.66 W / 7.12 W Access/Idle power consumption

Thermal durability and dynamic DC input for harsh environments

Advanced cooling mechanism guarantees an industrial thermal endurance level from -20˚C to 50˚C (-4˚F to 122˚F). EDS14 also tolerates dynamic DC input voltage from 7 to 24V and comes with support for PoE splitters, making it compatible with a variety of power sources.

Fan-less and drive-less design reduces vibration

The fan-less and drive-less design of EDS14 lowers the chance of hardware failure resulting from vibrations, while also delivering higher durability and reliability. Being EN50155 and EN45545 certified, EDS14 is resistant against shock, fire, vibration, and harsh environments found in moving vehicles and railway industries.

Flexible design for remote location deployment

The two 1GbE LAN ports and mobile network support (LTE dongle required) allows EDS14 to be deployed farther into remote locations with flexible network combinations. A schedulable DC output of up to 1A is available to power an external device where power outlets are out of reach.

Easy file access with QuickConnect

Access files on your Synology NAS over the Internet without the hassle of setting up port forwarding rules, DDNS, or other complicated network settings. QuickConnect allows you to connect via a secure, customizable address, so that you can instantly access media and work files on any Internet-connected device with no additional charge.





Hardware Specifications
CPU
CPU Model Marvell Armada 370 88F6707
CPU Architecture 32-bit
CPU Frequency 1.2 GHz
Floating Point
Hardware Encryption Engine
Memory
System Flash 4 GB eMMC
System Memory 512 MB DDR3
External Ports
RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
USB 2.0 Port 1
USB 3.0 Port 1
SD Card Reader
File System
External Drives
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+ (Read Only, with max. volume size 2TB)
Appearance
Size (Height x Width x Depth) 31 mm x 125 mm x 125 mm
Weight 0.295 kg
Others
Wireless Support (dongle)
Power Supply Unit / Adapter 24W
AC Input Power Voltage 100V to 240V AC
Dynamic DC Input 7-24V
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 8.66 W (Access)
7.12 W (Idle)
British Thermal Unit 29.55 BTU/hr (Access)
24.29 BTU/hr (Idle)
DC Output 1A
Temperature
Operating Temperature -20°C to 50°C (-4°F to 122°F)
Adapter Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • EN50155
  • EN45545
Warranty 3 Years
Notes Access power consumption is measured when loaded with Adata SDHC 8GB Class 10 SD card. Idle power consumption is measured with one LAN connected.
DSM Specifications ( See more )
File Sharing Capacity
Maximum Local User Accounts 128
Maximum Local Groups 64
Maximum Shared Folder 32
Maximum Shared Folder Sync Tasks 2
Maximum Concurrent CIFS/AFP/FTP Connections 128
NFS Kerberos Authentication
Add-on Packages (learn more about the complete add-on package list)
Cloud Station Server
Maximum Number of Concurrently Connected Devices 128
Maximum Number of Hosted Files (ext4) 10,000
Notes
  • The maximum number of concurrently connected devices refers to the maximum number of devices that can remain connected at the same time. For more information on file processing capability, please refer to the reaction time for file processing.
  • File reaction time refers to the preparation time required for other devices to start downloading a 10KByte file from a Synology NAS after the file has been added to the NAS. RAM expansion was not used during testing.
  • Non-encrypted shared folders were used during the aforementioned testing.
Download Station
Maximum Concurrent Download Tasks 50
Media Server
DLNA Certification
Surveillance Station
Maximum IP cam (Licenses required) 5 (including 2 Free License) (See All Supported IP Cameras)
Total FPS (H.264)* 150 FPS @ 720p (1280x720)
60 FPS @ 1080p (1920×1080)
40 FPS @ 3M (2048x1536)
30 FPS @ 5M (2591x1944)
Total FPS (MJPEG)* 90 FPS @ 720p (1280x720)
54 FPS @ 1080p (1920×1080)
36 FPS @ 3M (2048x1536)
20 FPS @ 5M (2591x1944)
Notes
  • When EDS14 works in an environment over 38°C, maximum IP camera will be lowered to 2 for the protection of your device. FPS information in H.264: 2 Ch @ 720P @ 60 FPS; 2 Ch @ 1080P @ 20 FPS; 1 Ch @ 3M @ 10; FPS; 1 Ch @ 5M @ 10 FPS. FPS information in MJPEG: 1 Ch @ 720P @ 20 FPS; 1 Ch @ 1080P @ 10 FPS; 1 Ch @ 3M @ 8 FPS; 1 Ch @ 5M @ 5 FPS
  • Surveillance Station throughput is tested with Axis P1347 (H.264@1280x720@30FPS), using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera. Recording video is saved every 5 minutes with the limit of archive folder up to 1GB.
Video Station
Video Transcoding Group 2 (See more)
VPN Server
Maximum Connections 5
Environment & Packaging
Environment RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Welcome Note X 1
  • AC Power Adapter X 1
  • RJ-45 LAN Cable X 1
  • VESA mounting kit
Optional Accessories
  • Surveillance Device License Pack
  • VS360HD
  • VS960HD

Login
