Technical Specifications
General
Device Interfaces
- IEEE 802.11ac wireless LAN1
- IEEE 802.11 a/b/g/n wireless LAN
- 10/100 fast Ethernet Internet port
- Four 10/100 fast Ethernet LAN ports
LEDs
- Power
- Internet
- WLAN
- LAN (x4)
- WPS
Antenna Type
- Three fixed external antennas
Operating Frequency
- 2.4 GHz band: 2400 - 2483.5 MHz
- 5 GHz band: 5150 - 5725 MHz
Standards
- IEEE 802.11ac
- IEEE 802.11n
- IEEE 802.11g
- IEEE 802.11b
- IEEE 802.11a
- IEEE 802.3u
Minimum Requirements
- Internet Explorer 9, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
- Cable or DSL Modem
- Subscription with an Internet Service Provider
Functionality
Security
- WPA & WPA2 (Wi-Fi Protected Access)
- WPS (Wi-Fi Protected Setup)
Advanced Features
- Web setup wizard
- DMZ (Demilitarized Zone)
- Firewall - Network Address Translation (NAT)
- Wireless Repeater
Physical
Dimensions
- 190 x 133 x 83 mm (7.48 x 5.24 x 3.27 inches)
Weight
- 228.6 grams (8.06 ounces)
Power
- Input: 100 to 240 V AC, 50/60 Hz
Temperature
- Operating: 0 to 40 °C (32 to 104 °F)
- Storage: -20 to 65 °C (-4 to 149 °F)
Humidity
- Operating: 10% to 90% non-condensing
- Storage: 5% to 95% non-condensing
Certifications
- ANATEL
- NCC
- CCC
- BSMI
1 Maximum wireless signal rate derived from draft IEEE 802.11ac and IEEE 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building
